- With Bluguard Security and Alarm System products, we provide security system that is designed to detect intrusion – unauthorized entry – into a building or area, such as hotels, malls, residential, commercial, industrial, and military properties for protection against burglary (theft) or property damage, as well as personal protection against intruders.
- A single purpose alarm systems of burglary protection or combination systems provide both fire and intrusion protection. Intrusion alarm systems can be combined with closed-circuit television surveillance systems to automatically record the activities of intruders, and may interface to access control systems for electrically locked doors. Systems range from small, self-contained noisemakers, to complicated, multi-area systems with computer monitoring and control.
A) L-Series Security
L900 Series Security
Bluguard L900 is streamlining a platform for intelligent security system, permitting all around 24/7 protections to your family. It embedded the tone feedback, call in/out functions, and home automation control under single coherent system. Bluguard L900 offers the intelligent 9 zones system to protect your family, apartment or office at a competitive cost. It comprises tone feedback and call in/ out users via the conventional phone line as the primary line and optional GSM line as the backup line. It offers the expansion room for optional module: GSM, Home Application and wireless solution as ease. Hence, customer will enjoy a low start up cost. 1) Product Features - 8 fully programmable onboard zones
- 1 special onboard zone:
— Panic button
— Remote or keyswitch arm/disarm function with siren/ strobe light indication - 8 User codes + 1 Duress code + 1 Installer code
- Built-in PSTN auto dialer
— CMS reporting with Contact ID format
— Personal reporting with tone feedback (beep sound) - Double call feature to bypass fax/answering machine during call in
- Auto ON HA points for zone alarm triggered
- Adjustable zone response for sensitivity
- Zone trip count feature to prevent false alarm
- Keypad lock feature to prevent password guessing
- Supports up to 4 Keypads, 2HA Modules (8HA points) and 1 GSM Module
- External Watchdog
- 485 communication bus
2) Compatible Accessories
- Support 4ea 9-zone LED keypad
- Support 2ea Home Automation Module (up to 8 points)
— HA06 Home Automation Module (1-way switch)
— HA07 Home Automation Module (2-way switch c/w IR learning) - Support 1ea GSM-200 GSM Module (9-zone)
- Support 1ea wireless module
— Unsupervised Wireless Module
— Supervised Wireless Module
| |
B) V-Series
V16N Series
Compare to tone alarm security system, V16N series is enhanced with state-of-the-art voice feedback to ensure you and your loved ones live in total comfort and safety.
1) Product Features - Innovative Voice Notification
— The innovative voice notification will report on the status of each zone Security Coverage
— 8 programmable zones with 2 partitions (expandable to 16 zones for wider security coverage) - Telephony Backup with GSM
— In case of tampered fixed lines or line disruptions, the system acts as a backup to SMS or call all preset numbers and report on your home’s status. - Easy Access Functions
— One-Touch system with easy access of functions via local keypad or mobiles - Stylish and Distinctive Keypad
— The keypad presents itself in an outstanding and modern design. - Home security integrated with home automation module
— Conveniently control and manage your home appliances such as lightings, air-conditioners and other appliances whether you’re at home or away - Secured Lightning Surge
— Secured lightning surge protection design up to 4kV - Connect to local PC for visual indication
— Allow user to view on home status on PC screen. In addition, user can control home automation points and adjust settings of security system
2) Compatible Accessories - Support up to 4ea keypad
— 16-zone LED Keypad
— 16-zone LCD Keypad - Support 1ea 8 Zone Expander Module
- Support 4ea Home Automation Module (up to 16 points)
— HA06 Home Automation Module (1-way switch)
— HA07 Home Automation Module (2-way switch c/w IR learning) - Support 1ea GSM-260 GSM Module (16-zone)
- RS232 – 485 Converter (For local PC Interface)
- Support maximum 2ea wireless module
— Unsupervised Wireless Module
— Supervised Wireless Module
| |
C) T Series Smart Home System
T32 Series
Your home is about living. With Bluguard automation and security system, your house can become a smart home, providing an enhanced lifestyle of - Entertainment, - Convenience, – Comfort & – Security.
1) Product Features - Security Coverage — 32 programmable zones for wider security coverage with 4 partitions
- Home Automation Control — Integrated the home automation that automated your home appliances
- GSM Module Solution — Higher protection with SMS reporting
- TCP/IP PC Interface — Allow remote control and monitoring via PC
- Unique Voice Feedback — Report on the status of each zone with customized vocabulary
- Build-in Speaker — Able to update users the condition of the system
- Easy Access Function — One-touch system with easy access of function via local keypad or mobile
2) Compatible Accessories - Support up to 4ea keypad — 32-zone LCD Keypad with Speaker — 32-zone LCD Keypad with Speaker
- Support 4ea Home Automation Module (up to 32 points) — HA06 Home Automation Module (1-way switch) — HA07 Home Automation Module (2-way switch c/w IR learning)
- Support 1ea GSM-320 GSM Module (32-zone)
- RS232 – 485 Converter (For local PC Interface)
- TCP/IP – 485 Converter (For network PC Interface)
- Support maximum 2ea wireless module — Unsupervised Wireless Module — Supervised Wireless Module
|
D) GSM Module
Stay alert of your home’s status, no matter where you are with GSM module. This 24-hours Telephony Monitoring system reports on your home’s status through instance SMS messages.
Compatible with all mobile networks, you will receive SMS messages on your home security system’s arm/disarm status and emergencies such as power failure or system trouble. In case of tampered fixed lines or line disruptions, the system will even be automatically activated as your normal telephone for out-going calls.
Is used in conjunction with a BluGuard Control Panel
- GSM-200 (9-zones) - for BluGuard Smart Bus L900 Series Control Panel
- GSM-269 (16-zones) – for BluGuard Smart Bus V16N & T16N Series Control Panel
Additional Features
- Standard Contact ID protocol for Central Monitoring Station
- Built-in Voice response module
- Standard DTMF for remote control
- Standard industrial SIM card
